| Truck Brand | Dongfeng |
| Overall dimensions(mm) | 7930×2500×3200 |
| Total mass (kg) | 18000 |
| Curb weight (kg) | 9480 |
| Fresh Water Tank Capacity(L) | 4000 |
| Hopper Capacity(L) | 8000 |
| Sweeping width(m) | 3.0~3.2(Adjustable) |
| Cleaning speed(km/h) | 3~20(Operating) |
| Maximum Cleaning Capacity(㎡/h) | ≥64,000 |
| Cleaning system components | Sweeping disk bracket, sweeping disk, oil cylinder, oil pipe, connecting rod, adjusting rod, hydraulic motor, etc. |
| Sweeping Brush Deployment Diameter | Φ800-900 |
| Number of Sweeping Disks |
4 |
| Number of Brushes per Sweeping Disk | 22 |
| The steel part around the suction nozzle in working state is ground clearance | 5~8mm |
| Water pump flow (L/min) | 122 |
| Engine power(kw) | 140 |
| Engine displacement(ml) | 4500 |
| Wheelbase(mm) | 4700 |
| Front and rear axle load | 6500/11500 |
| brake | Air brake |
| Tire size | 10.00R20 18PR |
After-sales and service
We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
Delivery Time
We do our best to ensure that orders are ready for dispatch within 24 working days (after payment is received)
Delivery areas
Whether you are in a bustling city or a quiet island, our global logistics network can seamlessly reach any sovereign country and region in the world.
