| Chassis brand | Sinotruk HOWO |
| Overall dimensions: L* W*H(mm) | 8760*2500*3150 |
| Water tank size(mm) | 4700*2300*1500 |
| Tank volume(L) | 15300 |
| Total mass(kg) | 25000 |
| Empty vehicle mass(kg) | 10950 |
| Rated load mass(kg) | 13920 |
| Wheelbase(mm) | 4300+1350 |
| Engine Model | MC07.29-60, 210kw |
| Engine displacement(ml) | 6870 |
| Gearbox | Sinotruk,8-speed |
| Front and rear axles(T) | 6.5/11X2 (drum brake) |
| Brake | Air brake |
| Emission standards | Euro 6 (Euro 2~5 can be selected) |
| Water cannon range(m) | 30 |
| Sprinkler width(m) | ＞15 |
| Vertical suction lift(m) | ＞7 |
| water pump flow(m³/h)/(l/min) | 60/1000 |
| water pump range(m) | 35 |
| Tire size | 11.00R20 |
| Standard Configuration: | The tank body is made of 4mm high-quality steel, with a sprinkler pump, sprinkler cannon, working platform, power take-off, front flushing, rear sprinkler, universal nozzle, gravity valve, filter, distribution valve, sprinkler head, with self-priming and self-draining function. |
| Optional equipment: | Spray potion tray, potion pump, anti-corrosion and anti-rust inside the water tank, multi-directional water inlet and outlet joints, solenoid valves, pneumatic valves, etc. to meet the needs of different users. |
After-sales and service
We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. If need, we will also send original spare parts free of charge by air.
Delivery Time
We do our best to ensure that orders are ready for dispatch within 24 working days (after payment is received)
Delivery areas
Whether you are in a bustling city or a quiet island, our global logistics network can seamlessly reach any sovereign country and region in the world.
